Measure Tire Tread in 90 Seconds – Rain or Shine

Handheld structured-light scanner | 0.1 mm accuracy | Bluetooth export

Rain or shine, this pocket-sized scanner reads all four tire tread depths in 90 s with 0.1 mm laser accuracy. Structured-light AI, IP54 rain mode, Bluetooth/Wi-Fi sync and instant PDF reports turn six-minute manual checks into a coffee-break inspection. CE/FCC certified, zero training required.

8

Key Highlights

• Proprietary laser-image (structured-light) analysis algorithm
• Rain-mode measurement with high success rate
• Patented exterior design and utility-model structural patents
• High accuracy and excellent repeatability
• Bluetooth & Wi-Fi connectivity for seamless device integration
• Professional inspection report with actionable tire-usage advice
• High-efficiency tread-data acquisition terminal ready for customer-platform integration

6

Handheld Tire Scanner

Automatic Mode

Measurement proceeds clockwise from the left-front tyre to the left-rear. After each groove’s data is captured, the probe automatically indexes to the next groove in sequence.

Manual Mode

At any time, the user can manually select any groove on any tyre. Once that measurement is complete, the system continues by automatically advancing to the next groove in the predefined order.

tire scanning 06

Inspection Report

Based on the measured tread depths of the four tires, the analysis covers overall wear, relative uneven wear, and the wear angle of each tire, followed by maintenance and service recommendations.

tire scanning 07
tire scanning 08
tire scanning 09
